Archive

726



Nominal impedance

4 Ω

Max. long-term power

250 W

Max. short-term power

400 W

Frequency range (±3 dB)

70–22000 Hz

Lf corner (−6 dB)

50 Hz

Crossover frequency

1500 Hz

Sensitivity (2.83 V/1 m)

93 dB

Speaker drivers

10" polyrpropylene mid-woofer;

1" aluminium-magnesium alloy dome tweeter by SEAS.

Dimensions (mm)

1067 H x 356 W x 108 D

Grill On-Wall

1067 H x 356 W x 8 D

Grill In-Wall

1140 H x 429 W x 10 D

Dimensions (inches)

42" H x 14" W x 4¼" D

Grill On-Wall

42" H x 14" W x ⅜" D

Grill In-Wall

44⅞" H x 17" W x ½" D

Weight

16 kg/35 lbs

186



Nominal impedance

8 Ω

Max. short-term power

130 W

Max. long-term power

200 W

Frequency range (±3 dB)

45–20000 Hz

Lf corner (−6 dB)

38 Hz

Crossover frequency

200/2100 Hz

Sensitivity (2.83 V/1 m)

90 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

2 × 4" polypropylene cone mid-woofer;

1" fabric dome tweeter.

Dimensions (mm)

1210 H × 168 W × 370 D

Base

240 W × 400 D

Dimensions (inches)

47¾" H × 6⅝" W × 14⅝" D

Base

9½" W × 15¾" D

Weight

27 kg/60 lbs

156



Nominal impedance

4 Ω

Max. short-term power

170 W

Max. long-term power

260 W

Frequency range (±3 dB)

37–20000 Hz

Lf corner (−6 dB)

32 Hz

Crossover frequency

160/4000 Hz

Sensitivity (2.83 V/1 m)

92 dB

Speaker drivers

10" paper cone woofer. Designed & manufactured by Audes;

5¼" paper cone mid-woofer;

1" fabric dome tweeter.

Dimensions (mm)

1030 H × 290 W × 370 D

Base

365 W × 410 D

Dimensions (inches)

40⅝" H × 11½" W × 14⅝" D

Base

14⅜" W × 16¼" D

Weight

20 kg/45 lbs

146



Nominal impedance

4 Ω

Max. short-term power

130 W

Max. long-term power

200 W

Frequency range (±3 dB)

39–20000 Hz

Lf corner (−6 dB)

34 Hz

Crossover frequency

250/4000 Hz

Sensitivity (2.83 V/1 m)

91 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

5¼" paper cone mid-woofer;

1" fabric dome tweeter.

Dimensions (mm)

1000 H × 235 W × 335 D

Base

300 W × 355 D

Dimensions (inches)

39⅜" H × 9¼" W × 13¼" D

Base

11⅞" W × 14" D

Weight

20 kg/45 lbs

136



Nominal impedance

8 Ω

Max. short-term power

70 W

Max. long-term power

100 W

Frequency range (±3 dB)

48–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1500 Hz

Sensitivity (2.83 V/1 m)

87 dB

Speaker drivers

2 × 5¼" polypropylene cone woofer;

1" fabric dome tweeter.

Dimensions (mm)

1140 H × 160 W × 195 D

Base

260 W × 260 D

Dimensions (inches)

49" H × 6⅜" W × 7¾" D

Base

10¼" W × 10¼" D

Weight

14 kg/31 lbs

116



Nominal impedance

8 Ω

Max. short-term power

75 W

Max. long-term power

100 W

Frequency range (±3 dB)

42–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter.

Dimensions (mm)

1000 H × 190 W × 230 D

Base

250 W × 250 D

Dimensions (inches)

39⅜" H × 7½" W × 9⅛" D

Base

9⅞" W × 9⅞" D

Weight

17 kg/38 lbs

106



Nominal impedance

8 Ω

Max. short-term power

75 W

Max. long-term power

100 W

Frequency range (±3 dB)

53–20000 Hz

Lf corner (−6 dB)

48 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter.

Dimensions (mm)

335 H × 190 W × 285 D

Stand

690 H × 275 W × 280 D

Dimensions (inches)

13¼" H × 7½" W × 11¼" D

Stand

27¼" H × 10⅞" W × 11¼" D

Weight

8 kg/18 lbs

155



Nominal impedance

4 Ω

Max. short-term power

120 W

Max. long-term power

260 W

Frequency range (±3 dB)

37–20000 Hz

Lf corner (−6 dB)

32 Hz

Crossover frequency

160/4000 Hz

Sensitivity (2.83 V/1 m)

92 dB

Speaker drivers

10" paper cone woofer. Designed & manufactured by Audes;

5¼" paper cone mid-woofer;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1030 H × 290 W × 370 D

Base

365 W x 410 D

Dimensions (inches)

40⅝ H × 11½ W × 14⅝ D

Base

14⅜ W × 16¼ D

Weight

31 kg/69 lbs

145



Nominal impedance

4 Ω

Max. long-term power

130 W

Max. short-term power

200 W

Frequency range (±3 dB)

39–20000 Hz

Lf corner (−6 dB)

34 Hz

Crossover frequency

250/4000 Hz

Sensitivity (2.83 V/1 m)

91 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

5¼" paper cone mid-woofer;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1000 H × 248 W × 295 D

Base

310 W × 330 D

Dimensions (inches)

39⅜" H × 9⅞" W × 11⅝" D

Base

12¼" W × 13" D

Weight

20 kg/45 lbs

115 (2007–2012)



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

42–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1000 H × 190 W × 230 D

Base

250 W × 250 D

Dimensions (inches)

39⅜" H × 7½" W × 9⅛" D

Base

9⅞" W × 9⅞" D

Weight

17 kg/38 lbs

105 (2007–2012)



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

53–20000 Hz

Lf corner (−6 dB)

48 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

335 H × 190 W × 285 D

Stand

690 H × 275 W × 280 D

Dimensions (inches)

13¼" H × 7½" W × 11¼" D

Stand

27¼" H × 10⅞" W × 11¼" D

Weight

8 kg/18 lbs

Poseidon



Soul



Nominal impedance

8 Ω

Max. long-term power

130 W

Max. short-term power

200 W

Frequency range (±2 dB)

38–20000 Hz

Lf corner (−6 dB)

32 Hz

Crossover frequency

300/3200 Hz

Sensitivity (2.83 V/1 m)

88 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

4½" paper cone midrange by SEAS;

1" fabric dome tweeter by SEAS.

Dimensions (mm)

1015 H × 290 W × 425 D

Base

325 W × 408 D

Dimensions (inches)

40" H × 11½" W × 16¾" D

Base

12⅞" W × 16⅛" D

Weight

40 kg/89 lbs

Bravo



Nominal impedance

8 Ω

Max. long-term power

40 W

Max. short-term power

70 W

Frequency range (±2 dB)

74–20000 Hz

Lf corner (−6 dB)

58 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

85 dB

Speaker drivers

5" paper cone mid-woofer by SEAS;

1" fabric dome tweeter by SEAS.

Dimensions (mm)

292 H × 155 W × 270 D

Dimensions (inches)

11½" H × 6⅛" W × 10¾" D

Weight

6 kg/14 lbs

Sympho



325IW



Nominal impedance

4 Ω

Max. power

120 W

Frequency range (±3 dB)

80–22000 Hz

Sensitivity (2.83 V/1 m)

92 dB

Speaker drivers

2 × 5" paper cone mid-woofer by SEAS;

1" fabric dome tweeter by SEAS.

Dimensions (mm)

576 H × 226 W × 82 D

Grill

614 H × 264 W × 7 D

Dimensions (inches)

22¾" H × 9" W × 3¼" D

Grill

24¼" H × 10½" W × ⅜" D

Weight

11 kg/25 lbs

305IW



Nominal impedance

4 Ω

Max. power

90 W

Frequency range (±3 dB)

80–22000 Hz

Sensitivity (2.83 V/1 m)

88 dB

Speaker drivers

5" paper cone mid-woofer by SEAS;

1" fabric dome tweeter by SEAS.

Dimensions (mm)

278 H × 278 W × 82 D

Grill

326 H × 326 W × 7 D

Dimensions (inches)

11" H × 11" W × 3¼" D

Grill

12⅞" H × 12⅞" W × ⅜" D

Weight

5 kg/12 lbs

535



Nominal impedance

4 Ω

Max. long-term power

120 W

Max. short-term power

160 W

Frequency range (±2 dB)

46–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

90 dB

Speaker drivers

2 × 6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter.

Dimensions (mm)

1170 H × 205 W × 340 D

Base

320 W × 380 D

Dimensions (inches)

46⅛" H × 8⅛" W × 13½" D

Base

12⅝" W × 15" D

Weight

27 kg/60 lbs

335



Nominal impedance

4 Ω

Max. long-term power

70 W

Max. short-term power

100 W

Frequency range (±2 dB)

80–20000 Hz

Lf corner (−6 dB)

60 Hz

Crossover frequency

2800 Hz

Sensitivity (2.83 V/1 m)

89 dB

Speaker drivers

2 × 5" paper cone woofer;

1" fabric dome tweeter.

Dimensions (mm)

1190 H × 155 W × 185 D

Base

315 W × 295 D

Dimensions (inches)

46⅞" H × 6⅛" W × 7⅜" D

Base

12½" W × 11⅝" D

Weight

15 kg/34 lbs

305



Nominal impedance

8 Ω

Max. long-term power

40 W

Max. short-term power

70 W

Frequency range (±2 dB)

90–20000 Hz

Lf corner (−6 dB)

70 Hz

Crossover frequency

2000 Hz

Sensitivity (2.83 V/1 m)

85 dB

Speaker drivers

5" paper cone woofer;

1" fabric dome tweeter.

Dimensions (mm)

325 H × 155 W × 230 D

Dimensions (inches)

12⅞" H × 6⅛" W × 9⅛" D

Weight

6 kg/14 lbs

CS 525



Nominal impedance

4 Ω

Max. long-term power

120 W

Max. short-term power

160 W

Frequency range (±2 dB)

53–20000 Hz

Lf corner (−6 dB)

44 Hz

Crossover frequency

2000 Hz

Sensitivity (2.83 V/1 m)

89 dB

Speaker drivers

2 × 6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter.

Dimensions (mm)

205 H × 630 W × 315 D

Dimensions (inches)

8⅛" H × 24⅞" W × 12½" D

Weight

15 kg/33 lbs

CS 325



Nominal impedance

4 Ω

Max. long-term power

70 W

Max. short-term power

100 W

Frequency range (±2 dB)

80–20000 Hz

Lf corner (−6 dB)

60 Hz

Crossover frequency

2800 Hz

Sensitivity (2.83 V/1 m)

89 dB

Speaker drivers

2 × 5" paper cone woofer;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

155 H × 610 W × 230 D

Dimensions (inches)

6⅛" H × 24⅛" W × 9⅛" D

Weight

9 kg/20 lbs

135



Nominal impedance

8 Ω

Max. long-term power

100 W

Max. short-term power

150 W

Frequency range (±3 dB)

40–20000 Hz

Lf corner (−6 dB)

36 Hz

Crossover frequency

800/3000 Hz

Sensitivity (2.83 V/1 m)

88 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1000 H × 248 W × 295 D

Base

310 W × 330 D

Dimensions (inches)

39⅜" H × 9⅞" W × 11⅝" D

Base

12¼" W × 13" D

Weight

20 kg/45 lbs

134



Nominal impedance

8 Ω

Max. long-term power

130 W

Max. short-term power

200 W

Frequency range (±3 dB)

38–20000 Hz

Lf corner (−6 dB)

34 Hz

Crossover frequency

800/3000 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

8" honeycomb woofer. Designed & manufactured by Audes;

1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1000 H × 248 W × 295 D

Base

310 W × 330 D

Dimensions (inches)

39⅜" H × 9⅞" W × 11⅝" D

Base

12¼" W × 13" D

Weight

22 kg/49 lbs

115 (2004–2007)



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

42–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1000 H × 200 W × 275 D

Base

265 W × 280 D

Dimensions (inches)

39⅜" H × 7⅞" W × 10⅞" D

Base

10½" W × 11⅛" D

Weight

17 kg/38 lbs

105 (2004–2007)



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

53–20000 Hz

Lf corner (−6 dB)

48 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

330 H × 200 W × 290 D

Dimensions (inches)

13" H × 7⅞" W × 11½" D

Weight

8 kg/18 lbs

105 (2000–2004)



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

55–20000 Hz

Lf corner (−6 dB)

48 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

360 H × 230 W × 280 D

Dimensions (inches)

14¼" H × 9⅛" W × 11⅛" D

Weight

8.5 kg/19 lbs

064



Nominal impedance

4 Ω

Max. long-term power

170 W

Max. short-term power

260 W

Frequency range (±3 dB)

38–20000 Hz

Lf corner (−6 dB)

32 Hz

Crossover frequency

800/4500 Hz

Sensitivity (2.83 V/1 m)

90 dB

Speaker drivers

10" paper cone woofer. Designed & manufactured by Audes;

2 × 1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1080 H × 310 W × 310 D

Dimensions (inches)

42⅝" H × 12¼" W × 12¼" D

Weight

30 kg/67 lbs

037



Nominal impedance

6 Ω

Max. long-term power

130 W

Max. short-term power

200 W

Frequency range (±3 dB)

38–20000 Hz

Lf corner (−6 dB)

33 Hz

Crossover frequency

320/1000/3800 Hz

Sensitivity (2.83 V/1 m)

90 dB

Speaker drivers

2 × 8" paper cone woofer. Designed & manufactured by Audes;

1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

1125 H × 260 W × 290 D

Base

310 W × 330 D

Dimensions (inches)

44⅜" H × 10¼" W × 11½" D

Base

12¼" W × 13" D

Weight

32 kg/71 lbs

017



Nominal impedance

8 Ω

Max. long-term power

100 W

Max. short-term power

150 W

Frequency range (±3 dB)

38–20000 Hz

Lf corner (−6 dB)

33 Hz

Crossover frequency

800/3000 Hz

Sensitivity (2.83 V/1 m)

88 dB

Speaker drivers

8" paper cone woofer. Designed & manufactured by Audes;

1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

930 H × 260 W × 290 D

Base

310 W × 330 D

Dimensions (inches)

36⅝" H × 10¼" W × 11½" D

Base

12¼" W × 13" D

Weight

22 kg/49 lbs

012



Nominal impedance

8 Ω

Max. long-term power

130 W

Max. short-term power

200 W

Frequency range (±3 dB)

36–20000 Hz

Lf corner (−6 dB)

32 Hz

Crossover frequency

800/3000 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

8" honeycomb woofer. Designed & manufactured by Audes;

1¾" fabric dome midrange. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

930 H × 260 W × 310 D

Base

310 W × 330 D

Dimensions (inches)

36⅝" H × 10¼" W × 12¼" D

Base

12¼" W × 13" D

Weight

22 kg/49 lbs

109



Nominal impedance

8 Ω

Max. long-term power

75 W

Max. short-term power

100 W

Frequency range (±3 dB)

41–20000 Hz

Lf corner (−6 dB)

37 Hz

Crossover frequency

1800 Hz

Sensitivity (2.83 V/1 m)

86 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

910 H × 215 W × 240 D

Base

265 W × 280 D

Dimensions (inches)

35⅞" H × 8½" W × 9½" D

Base

10½" W × 11⅛" D

Weight

15 kg/33 lbs

111



Nominal impedance

8 Ω

Max. long-term power

80 W

Max. short-term power

120 W

Frequency range (±3 dB)

52–20000 Hz

Lf corner (−6 dB)

45 Hz

Crossover frequency

2200 Hz

Sensitivity (2.83 V/1 m)

87 dB

Speaker drivers

6½" paper cone woofer. Designed & manufactured by Audes;

1" fabric dome tweeter. Designed & manufactured by Audes.

Dimensions (mm)

360 H × 230 W × 310 D

Dimensions (inches)

14¼" H × 9⅛" W × 12¼" D

Weight

10 kg/22 lbs

SW 108C



Nominal impedance

4 Ω

Max. short-term power

280 W

Lf corner (−8 dB)

34 Hz

Sensitivity (2.83 V/1 m)

91 dB

Speaker drivers

2 × 8" paper cone woofer. Designed & manufactured by Audes;

Dimensions (mm)

390 H × 630 W × 360 D

Dimensions (inches)

15⅜" H × 24⅞" W × 14¼" D

Weight

24 kg/53 lbs

SW 106C



Nominal impedance

4 Ω

Max. short-term power

300 W

Lf corner (−8 dB)

30 Hz

Sensitivity (2.83 V/1 m)

93 dB

Speaker drivers

2 × 10" paper cone woofer. Designed & manufactured by Audes;

Dimensions (mm)

370 H × 820 W × 360 D

Dimensions (inches)

14⅝" H × 32⅜" W × 14¼" D

Weight

24 kg/53 lbs

SW 104C



Nominal impedance

4 Ω

Max. short-term power

200 W

Lf corner (−8 dB)

32 Hz

Sensitivity (2.83 V/1 m)

90 dB

Speaker driver

10" paper cone woofer. Designed & manufactured by Audes;

Dimensions (mm)

380 H × 630 W × 370 D

Dimensions (inches)

15" H × 24⅞" W × 14⅝" D

Weight

18 kg/40 lbs
